Huba Control Differential Pressure Transmitter 692.918001161

Send Inquiry

Request To Call Back

Huba Control Differential Pressure Transmitter 692.918001161

Price 39500 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Huba Control Differential Pressure Transmitter 692.918001161 Specification

Max Pressure
0-4 Bar

Thread size
6 MM

Product Type
Huba Control Differential Pressure Transmitter 692.918001161

Max. Current
18-33 VDC

Max. Power
18-33 VDC

Max. Voltage
18-33 VDC Volt (V)

Pressure Range
0-4 Bar

Application
Process Medium; Gas

Output Signal
0 ... 5 V, 0 ... 10 V, 4 ... 20 mA

Size
(H) 95 x () 44

Rated Voltage
0-10 VDC / 24 VAC 15 % Volt (V)

Color
RAD

Usage & Applications
Process Medium; Gas

Weight
430 Grams (g)

Warranty
1 YERS

Rated Current
0-10 VDC / 24 VAC 15 %

Material
Stainless Steel 1.4305 (AISI 303); PVDF; CuZn Vni

Huba Control Differential Pressure Transmitter 692.918001161 Trade Information

Minimum Order Quantity
1 Piece

FOB Port
Delhi

Payment Terms
Paypal, Cash Against Delivery (CAD), Cash on Delivery (COD), Cash Advance (CA), Cash in Advance (CID), Cheque, Days after Acceptance (DA), Delivery Point (DP), Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Western Union, Letter of Credit (L/C)

Sample Policy
If order is confirmed we will reimburse the sample cost

Packaging Details
EXTRA

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Africa

Main Domestic Market
All India, South India, Central India, West India, North India, East India, Gujarat, Karnataka, Kerala, Lakshadweep, Mizoram, Meghalaya, Manipur, Andhra Pradesh, Bihar, Chandigarh, Daman and Diu, Goa, Jharkhand, Odisha, Punjab, Assam, Delhi, Dadra and Nagar Haveli, Andaman and Nicobar Islands, Arunachal Pradesh, Chhattisgarh, Haryana, Himachal Pradesh, Jammu and Kashmir, Madhya Pradesh, Maharashtra, Nagaland, Rajasthan, Sikkim, Tamil Nadu, Telangana, Tripura, Pondicherry, Uttar Pradesh, Uttarakhand, West Bengal

Certifications
EXTRA

About Huba Control Differential Pressure Transmitter 692.918001161

www.envirotechindustrialproducts.in

Huba Control Differential Pressure Transmitter 692.918001161

Brand : Huba Control

Model : 692.918001161

Range : 0-4 Bar

Type : 692 0-4 Bar

Current Out : 0-10 VDC / 24 VAC 15 %

IN - 18-33 VDC

Made In Switzerland

Huba Control Differential Pressure Transmitter 692

Product Information
Differential Pressure Transmitter 692

The Pressure Transmitters of Type 692 Feature The Unique And Proven Ceramic Technology. Depending On The Application, Various Pressure Connections And Electrical Connections With Standardized Output Signals Are Available. Due To The Wide Variety Of Options, The Transmitters 692 Are Suitable For All Types Of Industrial Applications.

Very Low Temperature Sensitivity

High Temperature Resistance

No Mechanical Creep

Individual Applications Through Modular System And Different Material Choices

Technical Data
Product Feature

Pressure Measuring Range : 0 ... 25 Bar (Relative And Difference)

Response Time : <5 ms

Load Change : <50 Hz

Sensor Weight : 430 g

Field Of Application

Media : Process Medium; Gas

Medium Temperature : -15 ... 85 C

Permissible Overload On One Side : See Variant Plan

System Pressure : 12; 25; 50 Bar

Bursting Pressure : 1.5 x System Pressure

Ambient Condition

Ambient Temperature : -15 ... 85 C

Storage Temperature : -40 ... 85 C

Material

Housing : Stainless Steel 1.4305 (AISI 303); PVDF

Pressure Connection With Media Contact : Stainless Steel 1.4305 (AISI 303); PVDF; CuZn Vni

Measuring Element With Media Contact : Ceramic Al2O3 (96 %)

Sealing Material With Media Contact : FPM; EDPM; NBR; MVQ; CR

Electrical Data

Current Consumption : <20 mA

Inverse-Polarity Protection : Short-Circuit And Reverse Polarity Protected. Each Connection Against Each Other With Max. Supply Voltage.

Installation Guide

Installation Orientation : any

Assembly : Mounting Bracket

Approval

EMC Compatibility : CE-Compliant In Accordance With EN 61326-2-3

Applications

REFRIGERATION SYSTEMS

CPU

WATER PUMPS

ULTRAFILTRATION SYSTEM

Accessories

Mounting Bracket

Socket Outlet DIN EN 175301-803-A : With Seal; IP 65, When Mounted And Screwed.

Socket Outlet DIN EN 60130-9 : IP 65, When Mounted And Screwed.

Calibration Certificate

Additional Information:

Item Code: Huba Control Differential Pressure Transmitter 692.918001161
WhatsApp No.9871034100,9868958924,9650264867,9716640145,8368866030,8368801023
www.envirotechindustrialproductsdelhi.com
www.envirotechindustrialproduct.info
www.envirotechindustrialproducts.info
www.envirotechdelhi.com

Reliable Process Control Across Gas Applications

The Huba Control Pressure Transmitter 692.918001161 delivers accurate differential pressure measurements in gas processing. Designed for the demands of modern industries, it features stainless steel construction for long-lasting performance and PVDF components for added chemical resistance. Its rugged build ensures functionality in varying industrial settings, making it ideal for manufacturers, exporters, distributors, and traders across India.

Flexible Output and Power Options

This transmitter supports multiple output signals-including 0-5 V, 0-10 V, and 4-20 mA-enabling compatibility with diverse industrial control systems. With a wide operating voltage range of 18-33 VDC or 24 VAC 15%, it integrates effortlessly into existing setups, offering reliable readings without complex installation requirements.

FAQ's of Huba Control Differential Pressure Transmitter 692.918001161:

Q: How do you install the Huba Control Differential Pressure Transmitter 692.918001161?

A: To install the transmitter, align its 6 mm thread with the designated connection point in your gas process line. Ensure correct wiring for your chosen output signal (0-5 V, 0-10 V, or 4-20 mA) and supply power within the specified voltage range (18-33 VDC or 24 VAC 15%). Detailed installation steps are provided in the user manual supplied by the manufacturer.

Q: What are the primary applications of this pressure transmitter?

A: This differential pressure transmitter is engineered for process medium applications involving gases, commonly used in monitoring, diagnostics, and control within industrial process systems, HVAC, and gas distribution sectors.

Q: When should the differential pressure transmitter be calibrated?

A: Calibration is recommended during initial installation, after any maintenance, or if you notice irregular readings. Regular annual calibration ensures ongoing accuracy and reliable performance throughout its lifespan.

Q: Where can I source or purchase the Huba Control 692.918001161 in India?

A: This transmitter is available through authorized distributors, exporters, importers, manufacturers, suppliers, traders, and wholesalers throughout India. Contact the designated supplier for genuine products and after-sales support.

Q: What is the benefit of using stainless steel 1.4305 (AISI 303) construction in this transmitter?

A: Using stainless steel 1.4305 (AISI 303) provides superior corrosion resistance and mechanical strength, making the transmitter suitable for harsh industrial environments and ensuring long operational life with minimal maintenance.

Q: How does the device enhance process safety and efficiency?

A: With its precise differential pressure monitoring, the transmitter helps in early detection of pressure variations, minimizing operational risks, optimizing performance, and reducing downtime in process gas systems.
