GEMTECH Series 3000 Digital Pressure Gauge Range 0 to 3.000 KPA

Send Inquiry

Request To Call Back

GEMTECH Series 3000 Digital Pressure Gauge Range 0 to 3.000 KPA

Price 19500 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

GEMTECH Series 3000 Digital Pressure Gauge Range 0 to 3.000 KPA Specification

Outer Size
4" (101.6 MM) Diameter Dial Face.

Display
LCD

Sensor Type
GEMTECH Series 3000 Digital Pressure Gauge Range 0 to 3.000 KPA

Thread
1/8" female NPT duplicate high and low pressure taps - one pair side and one pair back

Usage
POWER PLANT,CEMENT PLANT,STEEL PLANT,FERTILIZER,TEXTILE

Dial Material
Plastic

Size
4" (101.6 MM) Diameter Dial Face.

Pointer Material
Plastic

Processing Type
Standard

Product Type
GEMTECH Series 3000 Digital Pressure Gauge Range 0 to 3.000 KPA

Diameter
4 inch / 100 MM

Color
WHITE / BLACK

Mount Type
Back

Scale Range
GEMTECH Series 3000 Digital Pressure Gauge Range 0 to 3.000 KPA

Accuracy
0.5%

GEMTECH Series 3000 Digital Pressure Gauge Range 0 to 3.000 KPA Trade Information

Minimum Order Quantity
1 Piece

FOB Port
Delhi

Sample Policy
If order is confirmed we will reimburse the sample cost

Packaging Details
EXTRA

Main Domestic Market
All India, South India, Central India, West India, North India, East India, Gujarat, Karnataka, Kerala, Lakshadweep, Mizoram, Meghalaya, Manipur, Andhra Pradesh, Bihar, Chandigarh, Daman and Diu, Goa, Jharkhand, Odisha, Punjab, Assam, Delhi, Dadra and Nagar Haveli, Andaman and Nicobar Islands, Arunachal Pradesh, Chhattisgarh, Haryana, Himachal Pradesh, Jammu and Kashmir, Madhya Pradesh, Maharashtra, Nagaland, Rajasthan, Sikkim, Tamil Nadu, Telangana, Tripura, Pondicherry, Uttar Pradesh, Uttarakhand, West Bengal

Certifications
EXTRA CHARGES

About GEMTECH Series 3000 Digital Pressure Gauge Range 0 to 3.000 KPA

GEMTECH Series 3000 Digital Pressure Gauge Range 0 to 3.000 KPA.

GEMTECH Series 3000 Digital Pressure Gauge Range 0 to 3.000 KPA

Thank You For Choosing Our Digital Differential Pressure Gauge.Please Read This Manual Before Using If You Have Any Doubt About The Use,Please Feel Free To Contact Our Company,We Are Quite Willing To Serve You

MATTERS NEEDING ATTENTION
Please Do Not Modify The Internal Wiring And Lines Of The Digital Differential Pressure Gauge By Your Self Please Choose a Safe Area To Install The Digital Differential Pressure Gauge To Prevent High Temperature And Avoid Splashing Of Moisture And Water Droplets When The Battery Voltage Is Low,Please Replace The Battery In Time

RELEVANT MATTERS BEFORE USE DELIVERY INSPECTION

Each Differential Pressure Transmitter is Subject to Strict Quality Control Before Delivery.Product Packaging Adopts Enhanced Anti-Collision Treatment. After Opening The Box,Please Check Whether The Product Caused Damage During The Transportation

APPLICATIONS AND FEATURES

Using High-Precision Sensors And Digital Technology,Can Detect Positive Pressure,Negative Pressure Or Differential Pressure
Can Be Widely Used To Measure The Pressure Of Fans And Blowers Filter Resistance Wind Speed Furnace Ventilation Pressure Drop Caused By Orifice Plates,Liquid Level In Foaming Systems And Pressure In Booster Or Hydraulic Systems
Can Be Used On Medical Equipment To Monitor Blood And Respiratory Pressure
Suitable For Embedded Installation,Flat Installation And Other Installation Methods

PRODUCTS SHEET

Various Measuring Ranges
No Moving Parts,Anti-Vibration
Accuracy Up To i1%FS, i3%FS(0-60Pa),i2%FS(0-125Pa)
Button Function:Zero Calibration,Unit Switching

STORAGE AND INSTALLATION

The Product Should Be Kept In a Dry And Grime Free Place
Storage Temperature:-10i+40i
Storage Humidity:0%90%
Vibration:20Hz: 9.8 m/s2 (1G) max;20Hz50Hz:5.88 m/s2 (0. 6G) Max
Avoid Storing in Corrosive Gas And Liquid Environment
It is Best to Store It Properly Packaged On a Shelf Or Table
If it is used in an open package and it exceeds 3 months,The ambient temperature of the storage environment should not be higher than 30 i.This is because when the electrolytic capacitor is stored without electricity,its characteristics are easily deteriorated when the ambient temperature is too high.Do not leave it for more than a year without electricity
Ambient Temperature:-10+50i (14104i)
Ambient Relative Humidity:<90%,no frost
Installation Height:<1000m

On a circle with a diameter of 105mm,drill 3 holes with an average angle of 120 degrees.The hole diameter is between 3-3.2 (as shown in the picture above). Mounted on The Surface With Accessory Screws M3X8.Choose one Pair of Pressure ports to connect to the Air Tube,Pay attention to the Difference Between High and Low Pressure Ports,And Make Sure to Seal the other pair of pressure ports with On the plate that needs to be embedded,punch a hole, the diameter of the hole is between 114 and 3-114.8mm.Embed the product and install the accessory feet on the back.Then fix it on the plate with M3.5X50 self-tapping screws.Choose one of the pair of pressure ports to connect to the Airway Note the Difference Between High/Low Pressure Ports And Make Sure To Seal The Other

PRODUCT PARAMETERS

Medium:Air And Non-Flammable,Non-Corrosive Gas
Medium Temperature: 0-60C
Shell:ABS Engineering Plastic
Working Environment:-20C+85C
Differential Pressure Range:a variety of Ranges.Overload 3xFS,Breaking pressure 10iFS
Long-Term Stability:i0.1% FS/Year
Temperature Drift Coefficient: <0.03% FS/C
Power Supply:4 AA Batteries / 24 VDC

COMPLETE RANGE MODAL

RANGE

CODE	UNIT & RANGE
	PA	PA	KPA	MBAR	MM W.C	IN W.C
1	0-60	60.00	0.060	0.600	6.000	0.250
2	0-125	125.0	0.125	1.250	12.00	0.500
3	0-250	250.0	0.250	2.500	25.00	1.000
4	0-500	500.0	0.500	5.000	50.00	2.000
5	0-750	750.0	0.750	7.500	75.00	3.000
6	0-1000	1000	1.000	10.00	100.0	4.000
7	0-2000	2000	2.000	20.00	200.0	8.000
8	0-3000	3000	3.000	30.00	300.0	12.00
9	0-5000	5000	5.000	50.00	500.0	20.00
10	0-10000	10000	100.0	100.0	1000	10.00

OPTIONAL RANGE : i30PA-i5000PA (0-10000PA)

Additional Information:

Item Code: GEMTECH Series 3000 Digital Pressure Gauge Range 0 to 3.000 KPA
WhatsApp No.9871034100,9868958924,9650264867,9716640145,8368866030,8368801023
www.envirotechindia.co.in
www.envirotechdelhi.in
www.envirotechdelhi.net
www.envirotechindia.info
www.envirotechdelhi.info
www.envirotechindia.net
www.envirotechdelhi.co.in

GEMTECH Series 3000 Digital Pressure Gauge Range 0 to 3.000 KPA.

Versatile Industrial Application

Designed to meet the rigorous standards of industries such as power, cement, steel, fertilizer, and textiles, the GEMTECH Series 3000 Digital Pressure Gauge delivers reliability and adaptability. Its wide pressure range and robust construction offer precise monitoring for a variety of operational settings, supporting maintenance and process optimization.

User-Friendly Digital Display

Equipped with an easy-to-read LCD screen, this pressure gauge allows users to quickly and accurately monitor system pressure at a glance. The display enhances usability in busy industrial spaces where quick data interpretation is essential.

FAQ's of GEMTECH Series 3000 Digital Pressure Gauge Range 0 to 3.000 KPA:

Q: How does the GEMTECH Series 3000 Digital Pressure Gauge measure pressure?

A: The gauge uses an advanced sensor and digital technology to measure pressure within the 0 to 3.000 KPA range, displaying the results clearly on an LCD screen for easy reading.

Q: What installation options are available for this gauge?

A: The gauge features a back mount design and comes with 1/8" female NPT duplicate high and low pressure taps on both the side and back, providing flexible mounting and connection choices for various industrial setups.

Q: When should I use this pressure gauge in my plant operations?

A: The GEMTECH Series 3000 is suitable for continuous or periodic monitoring of pressure in power, cement, steel, fertilizer, and textile plants, helping to ensure safe and efficient system performance.

Q: Where is the GEMTECH Series 3000 pressure gauge manufactured and distributed?

A: This product is manufactured, distributed, exported, imported, and supplied throughout India by a network of authorized distributors and dealers.

Q: What benefits does this digital pressure gauge offer over analog models?

A: Digital models provide superior accuracy (0.5%), quicker readings, and a user-friendly LCD display, reducing the incidence of human error and improving operational efficiency.

Q: How do I maintain the accuracy of the GEMTECH Series 3000?

A: Regular calibration and proper installation as per the manufacturer's guidelines help preserve the gauge's accuracy and ensure optimal performance for industrial applications.
