GEMTECH Series 3000 Digital Pressure Gauge Range 0 to 0.060 KPA

Send Inquiry

Request To Call Back

GEMTECH Series 3000 Digital Pressure Gauge Range 0 to 0.060 KPA

Price 19500 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

GEMTECH Series 3000 Digital Pressure Gauge Range 0 to 0.060 KPA Specification

Display
LCD

Thread
1/8" female NPT duplicate high and low pressure taps - one pair side and one pair back

Sensor Type
GEMTECH Series 3000 Digital Pressure Gauge Range 0 to 0.060 KPA

Usage
POWER PLANT,CEMENT PLANT,STEEL PLANT,FERTILIZER,TEXTILE

Dial Material
Plastic

Pointer Material
Plastic

Size
4" (101.6 MM) Diameter Dial Face.

Processing Type
Standard

Product Type
GEMTECH Series 3000 Digital Pressure Gauge Range 0 to 0.060 KPA

Diameter
4 inch / 100 MM

Weight
550 Grams (g)

Color
WHITE / BLACK

Mount Type
Back

Scale Range
MM WC/ CM / PAC / KPA / INCH / PSI / MBAR

Accuracy
0.5%

Measure Pressure Of
Gas

Remote Battery Type
AAA

Refresh Rate
60 Hz

USB Ports
2

Sleep Timer
Yes

Smart TV Features
Built-in WiFi, Screen Mirroring

Operating System
Android

Viewing Angle
178

GEMTECH Series 3000 Digital Pressure Gauge Range 0 to 0.060 KPA Trade Information

Minimum Order Quantity
1 Piece

FOB Port
Delhi

Payment Terms
Paypal, Cash Against Delivery (CAD), Cash on Delivery (COD), Cash Advance (CA), Cash in Advance (CID), Cheque, Days after Acceptance (DA), Delivery Point (DP), Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Western Union, Letter of Credit (L/C)

Sample Policy
If order is confirmed we will reimburse the sample cost

Packaging Details
EXTRA

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India, South India, Central India, West India, North India, East India, Gujarat, Karnataka, Kerala, Lakshadweep, Mizoram, Meghalaya, Manipur, Andhra Pradesh, Bihar, Chandigarh, Daman and Diu, Goa, Jharkhand, Odisha, Punjab, Assam, Delhi, Dadra and Nagar Haveli, Andaman and Nicobar Islands, Arunachal Pradesh, Chhattisgarh, Haryana, Himachal Pradesh, Jammu and Kashmir, Madhya Pradesh, Maharashtra, Nagaland, Rajasthan, Sikkim, Tamil Nadu, Telangana, Tripura, Pondicherry, Uttar Pradesh, Uttarakhand, West Bengal

Certifications
EXTRA CHARGES

About GEMTECH Series 3000 Digital Pressure Gauge Range 0 to 0.060 KPA

GEMTECH Series 3000 Digital Pressure Gauge Range 0 to 0.060 KPA.

GEMTECH Series 3000 Digital Pressure Gauge Range 0 to 0.060 KPA

GEMTECH _ Series 3000 Digital Pressure Gauge Range 0 to 1.000 KPA Thank You For Choosing Our Digital Differential Pressure Gauge.Please Read This Manual Before Using If You Have Any Doubt About The Use,Please Feel Free To Contact Our Company,We Are Quite Willing To Serve You MATTERS NEEDING ATTENTION Please Do Not Modify The Internal Wiring And Lines Of The Digital Differential Pressure Gauge By Your Self Please Choose a Safe Area To Install The Digital Differential Pressure Gauge To Prevent High Temperature And Avoid Splashing Of Moisture And Water Droplets When The Battery Voltage Is Low,Please Replace The Battery In Time RELEVANT MATTERS BEFORE USE DELIVERY INSPECTION Each Differential Pressure Transmitter is Subject to Strict Quality Control Before Delivery.Product Packaging Adopts Enhanced Anti-Collision Treatment. After Opening The Box,Please Check Whether The Product Caused Damage During The Transportation APPLICATIONS AND FEATURES

Using High-Precision Sensors And Digital Technology,Can Detect Positive Pressure,Negative Pressure Or Differential Pressure
Can Be Widely Used To Measure The Pressure Of Fans And Blowers Filter Resistance Wind Speed Furnace Ventilation Pressure Drop Caused By Orifice Plates,Liquid Level In Foaming Systems And Pressure In Booster Or Hydraulic Systems
Can Be Used On Medical Equipment To Monitor Blood And Respiratory Pressure
Suitable For Embedded Installation,Flat Installation And Other Installation Methods

PRODUCTS SHEET

Various Measuring Ranges
No Moving Parts,Anti-Vibration
Accuracy Up To 1%FS, 3%FS(0-60Pa),2%FS(0-125Pa)
Button Function:Zero Calibration,Unit Switching

STORAGE AND INSTALLATION

The Product Should Be Kept In a Dry And Grime Free Place
Storage Temperature:-10+40
Storage Humidity:0%90%
Vibration:20Hz: 9.8 m/s2 (1G) max;20Hz50Hz:5.88 m/s2 (0. 6G) Max
Avoid Storing in Corrosive Gas And Liquid Environment
It is Best to Store It Properly Packaged On a Shelf Or Table
If it is used in an open package and it exceeds 3 months,The ambient temperature of the storage environment should not be higher than 30 .This is because when the electrolytic capacitor is stored without electricity,its characteristics are easily deteriorated when the ambient temperature is too high.Do not leave it for more than a year without electricity
Ambient Temperature:-10+50 (14104)
Ambient Relative Humidity:<90%,no frost
Installation Height:<1000m

On a circle with a diameter of 105mm,drill 3 holes with an average angle of 120 degrees.The hole diameter is between 3-3.2 (as shown in the picture above). Mounted on The Surface With Accessory Screws M3X8.Choose one Pair of Pressure ports to connect to the Air Tube,Pay attention to the Difference Between High and Low Pressure Ports,And Make Sure to Seal the other pair of pressure ports with On the plate that needs to be embedded,punch a hole, the diameter of the hole is between 114 and 3-114.8mm.Embed the product and install the accessory feet on the back.Then fix it on the plate with M3.5X50 self-tapping screws.Choose one of the pair of pressure ports to connect to the Airway Note the Difference Between High/Low Pressure Ports And Make Sure To Seal The Other PRODUCT PARAMETERS

Medium:Air And Non-Flammable,Non-Corrosive Gas
Medium Temperature: 0-60C
Shell:ABS Engineering Plastic
Working Environment:-20Ci+85C
Differential Pressure Range:a variety of Ranges.Overload 3xFS,Breaking pressure 10FS
Long-Term Stability:0.1% FS/Year
Temperature Drift Coefficient: <0.03% FS/C
Power Supply:4 AA Batteries / 24 VDC

OPTIONAL RANGE : 30PA-5000PA (0-10000PA) Additional Information:

Item Code: GEMTECH Series 3000 Digital Pressure Gauge Range 0 to 0.060 KPA
WhatsApp No.9871034100,9868958924,9650264867,9716640145,8368866030,8368801023
www.envirotechindustrialproduct.net
www.envirotechindustrialproductsindia.in
www.envirotechindustrialproductsdelhi.com
www.envirotechindustrialproduct.info
www.envirotechindustrialproducts.info
www.envirotechdelhi.com
www.envirotechindia.co.in

GEMTECH Series 3000 Digital Pressure Gauge Range 0 to 0.060 KPA.

Accurate Multi-Unit Gas Pressure Measurements

The GEMTECH Series 3000 Digital Pressure Gauge offers versatility through its multiple scale ranges: MM WC, CM, PAC, KPA, INCH, PSI, and MBAR. Designed specifically for gas measurement, it provides 0.5% accuracy, ensuring reliable and precise readings, ideal for critical processes in industrial plants.

Adaptable Installation for Industrial Needs

Featuring side and back pressure taps and a 1/8" female NPT thread, the gauge accommodates varied installation requirements. The 4-inch (101.6 mm) dial with back mount simplifies integration into control panels across sectors like power, cement, steel, fertilizer, and textiles.

User-Friendly Digital Display and Build Quality

Equipped with an easy-to-read LCD display and a robust plastic housing, the GEMTECH Series 3000 ensures longevity and visibility in demanding environments. The plastic pointer and 550-gram weight provide both durability and practicality for frequent industrial use.

FAQ's of GEMTECH Series 3000 Digital Pressure Gauge Range 0 to 0.060 KPA:

Q: How do I install the GEMTECH Series 3000 Digital Pressure Gauge in my facility?

A: Installation is straightforward thanks to its back mount design and 1/8" female NPT threaded taps, which are provided on both the side and back. You can choose the most convenient tap for your setup, ensuring the gauge integrates seamlessly into various industrial applications.

Q: What gas pressures can the Series 3000 gauge measure, and what is the accuracy?

A: This gauge is calibrated for precise measurement of gas pressure in the range of 0 to 0.060 KPA, with a measurement accuracy of 0.5%. Multiple scale units allow you to select the display format best suited to your application.

Q: Where is this pressure gauge typically used?

A: The GEMTECH Series 3000 is widely used in power plants, cement factories, steel manufacturing units, fertilizer plants, and textile mills throughout India, thanks to its reliability and adaptability.

Q: What is the process for switching between different scale units on the dial?

A: The gauge is designed with a multi-scale dial, allowing you to visually interpret readings in MM WC, CM, PAC, KPA, INCH, PSI, or MBAR as required. No recalibration is needed to interpret different units since they are all displayed on the dial face.

Q: How does the LCD display benefit daily operations?

A: The clear LCD display makes it easy to monitor pressure readings quickly and accurately, even in low-light or high-activity environments. This helps operators maintain safety and efficiency during continuous plant operations.

Q: What advantages does the duplicate pressure tap design offer?

A: Having both side and back pairs of high and low pressure taps provides installation flexibility, allowing the gauge to be positioned for optimal accessibility and maintenance in confined or varied industrial layouts.

Q: What maintenance is required for optimal gauge performance?

A: Periodic inspection for debris, calibration checks, and verifying connections are recommended. The robust plastic exterior and pointer require minimal upkeep, further supporting reliable, long-term operation in demanding industrial settings.
