Winters Instruments Canada Digital Pressure Gauge MODEL DPG212 RANGE 0 To 30 PSI

About Winters Instruments Canada Digital Pressure Gauge MODEL DPG212 RANGE 0 To 30 PSI

Winters Instruments Canada Digital Pressure Gauge MODEL DPG212 RANGE 0 To 30 PSI

• MODEL - DPG212
• RANGE - 0-30 PSI


Description & Features

• Simple 2 Button Operation
• Reset To Zero Feature
• Backlight Turns On When On/Off Button Is Pressed
• Option For Display To Remain Continuously On
• Continuous Peak Pressure Indication Option
• 316L Welded Diaphragm Seal
• Rubber Boot Is Standard
• ASME B40.100 Compliant
• RoHS Compliant
• +/- 1% Accuracy (+-/ 0.5% Optional For Gauges Up to 5000 PSI)
• 1 Year Warranty


Applications

• Ideal For Commercial And Industrial Applications In Both Test Measurement And General Purpose Installations



Specifications
Case Size	2.5" (63MM)
Case Material	ABS (IP64)
Rubber Boot	Silicone Rubber (IP65)
LCD Display	2" x 3/4" (48MM x 16MM)
Connection	1/4" NPT 304SS
Sensor	316L Welded,Piezo
Operation Life	1 Million Cycles
Power Supply	2 x AAA Battery (1.5V)
Battery Life	2 Yrs (Auto Shut-Off Mode)
Power Mode	Auto or Manual Shut-Off
Display Digits	4 digits to 5000 psi,5 digits for 10000 psi
Resolution	psi,mmHO,mmHg,mbar,kPa 100 psi
	psi, bar, kg/cm ,mPa,atm ranges 160 psi
Operation Mode	Continuously Reading or Peak Pressure Reading
Response Time	3 Hz Display Refresh Rate
Proof/Burst Pressure	200%/300% FS
Operating/Storage Temperature	14F to 122F (-10C to 50C)
	-4F to 167F (-20C to 75C)
Accuracy	0.5%
Dial Size	2.5" (63mm
Connection	1/4" Bottom
Socket	SS

Additional Information:

• Item Code: Winters Instruments Canada Digital Pressure Gauge MODEL DPG212 RANGE 0 To 30 PSI
• MOBIL NO. 9871034100,9868958924
• www.envirotechdelhi.info
• www.envirotechindia.net
• www.envirotechdelhi.co.in

Versatile Applications Across Multiple Industries

Whether in pharmaceutical labs or heavy-duty steel plants, the DPG212 adapts to a range of settings. Its compatibility with major industrial sectors like power, cement, and fertilizer production ensures this gauge delivers accurate readings even in rigorous environments. Back mounting allows for straightforward integration into existing systems, offering consistent performance where precision is essential.


Stainless Steel Construction for Long-lasting Durability

With a full 304 stainless steel body and thread, the DPG212 withstands corrosion and physical wear. This design choice ensures optimal longevity in challenging operating conditions, making it suitable for exporter, manufacturer, supplier, and distributor needs. Its robust build supports a scale range of up to 30 PSI, with clear digital output at both low and high pressures.
