Huba Control Differential Pressure Switch Model 604.99957 Range 0.2....3 Mbar

Send Inquiry

Request To Call Back

Huba Control Differential Pressure Switch Model 604.99957 Range 0.2....3 Mbar

Name: Huba Control Differential Pressure Switch Model 604.99957 Range 0.2....3 Mbar
Brand: ENVIRO TECH INDUSTRIAL PRODUCTS
Price: 4800 INR
Availability: InStock

Price 4800 INR/ Piece

Get a Price/Quote

MOQ : 30 Pieces

Huba Control Differential Pressure Switch Model 604.99957 Range 0.2....3 Mbar Specification

Working Temperature
-20C to +85C

Thread size
6 mm tube connection

Mechanical Life
>106 switching cycles

Max Pressure
50 mbar (maximum system pressure)

Function
Monitors and switches based on differential pressure

Product Type
Differential Pressure Switch

Max. Current
1.5 A (at 250 VAC)

Max. Power
50 VA

Max. Voltage
250 VAC

Protection Class
IP54

Pressure Range
0.2...3 mbar

Application
HVAC, air and non-aggressive gases monitoring, industrial automation

Output Signal
Switching contact (SPDT)

Size
Installation dimensions: 82 x 82 x 55 mm

Color
Grey/Black

Weight
Approx. 180 g

Media Compatibility
Air and non-aggressive gases

Storage Temperature
-40C to +85C

Mounting Position
Any position (preferably vertical)

Repeatability
0.1 mbar

Approval/Standard
CE marked, RoHS compliant

Diaphragm Material
Silicone

Contact Material
Silver alloy

Switching Differential
Fixed (approximately 0.2 mbar)

Electrical Connection
Flat male connectors 6.3 x 0.8 mm

Setting Range
0.2 to 3 mbar adjustable

Housing Material
ABS plastic housing

About Huba Control Differential Pressure Switch Model 604.99957 Range 0.2....3 Mbar

www.envirotechdelhi.net

Huba Control Differential Pressure Switch Model 604.99957 Range 0.2....3 Mbar

Model : 604.99957

Range : 0.2....3 Mbar

Max : 50 Mbar ( -30T85 )

Max : 50 Mbar ( -30T75 )

Made In Switzerland

Product information
The Pressure Switches of Type 604 Monitor Filters and Fans in Ventilation Ducts As Well As Air Dampers In Primary/Secondary Controls in p Function The Series Divided Into Five Pressure Range Gradations Impresses With Extreme Ease Of Installation Combination Brackets,Snap-On Covers,And Screw Terminals.Unique Is The High Adjustment Accuracy Through Individual Scale Engraving

Easy To Install

User-Friendly Snap Closure For The Cover

Cable Entry Aid

Cable Strain Relief Integrated Into PG11

Combination Bracket For Vertical Or Horizontal Mounting

High Adjustment Accuracy Through Individual Scale Engraving Per Switch

Long-Term Stable Switching Points Through Trapezoidal Bead Membrane

Multilayer Contact With Gold Plating

Product Feature

Technical Data

Pressure Measuring Range:0...50 Mbar Relative & Difference

Sensor Weight:143g With Type C combination bracket

Field Of Application

Media:Air Neutral Gas

Medium Temperature:-30...85C

Permissible Overload On One Side:75 Mbar-30...75C 50 Mbar-30...85C

Ambient Condition

Ambient Temperature:-30... 85C

Storage Temperature:-40...85C

Material

Housing With Media Contact:PC 10% GF

Measuring Element With Media Contact:Silicone LSR Tempered At 200C,Outgassing-Free

Cover With Media Contact:PC

Electrical Data

Switching Load:5 A at 250 VAC

Resistive Switching Load:4 A at 30 VDC

Inductive Switching Load:0.8 A at 250 VAC 0.7 A at 30 VDC

Switching Load GAR Application:1 A at 250 VAC 0.2 A at 30 VDC

Contact System:Changeover Switch

Lifespan:>10000000 Schaltspiele Mechanical

Installation Guide

Installation Orientationany:Any Recommendation Vertical Pressure Connections Downwards Factory Adjustment Any Recommendation Horizontal Cover Down Switching Points Are Approx 11 Pa Lower Than The Set Scale Value Any Recommendation Horizontal Cover Upward Switching Points Are Approx 11 Pa Higher Than The Set Scale Value

Approval

UL:MFHX2/8 Or XAAK2/8

DVGW:According to DIN EN 1854

Low Voltage Directive:2014/35/EU

Gas Appliances Directive:2016/426/EU

Applications
AHU

CRAC

MOBILE HYDRAULIC

Accessories

Connection Set Straight:For Ventilation Duct Including 2 M Hose Plastic

Angle Type B

Combination Bracket Type C

Snap Ring:For Angle A,B,C Or Direct Mounting For Wall Thickness 1.8...2.1 MM

Snap Ring:For Angle A,B,C Or Direct Mounting For Wall Thickness 0.8...1.1 MM

Angle Type A

Fastening Screw:For Wall Thickness 1-2 MM Screw Length 6 MM Min 2 Screws Required

Connection Set 90 Angled:For Ventilation Duct Including 2 M Hose Metal

Calibration Certificate

Mounting Ring

Closed Fastening Ring

Additional Information:

Item Code: Huba Control Differential Pressure Switch Model 604.99957 Range 0.2....3 Mbar
WhatsApp No.9871034100,9868958924,9650264867,9716640145,8368866030,8368801023
www.envirotechdelhi.info
www.envirotechdelhi.net
www.envirotechindia.info

www.envirotechdelhi.net

Versatile Differential Pressure Monitoring

The Huba Control Model 604.99957 excels at monitoring differential pressure in air and non-aggressive gas applications. With an adjustable range from 0.2 to 3 mbar, it supports precise settings tailored to specific requirements. The robust construction allows operation across a wide temperature span, while its compatibility with a variety of HVAC and industrial automation applications makes it a preferred choice for reliable system monitoring.

Robust Build and High Repeatability

This pressure switch is constructed using ABS plastic housing and a silicone diaphragm, ensuring resistance to environmental challenges and a repeatability of 0.1 mbar. Certified to CE and RoHS standards, it delivers consistent performance through over a million switching cycles, making it well-suited for long-term operation in critical applications.

FAQ's of Huba Control Differential Pressure Switch Model 604.99957 Range 0.2....3 Mbar:

Q: How can the Huba Control 604.99957 pressure switch be installed for optimal operation?

A: The Model 604.99957 can be mounted in any position, although vertical installation is recommended for the most precise performance. Installation is straightforward, with 6 mm tube connections for media input and flat male electrical connectors for wiring.

Q: What are the typical usage scenarios for this differential pressure switch?

A: This switch is commonly used in HVAC systems, as well as for monitoring air and non-aggressive gases in industrial automation processes. Its ability to provide accurate pressure monitoring and switching makes it essential for ensuring system safety and operational efficiency.

Q: When is it necessary to adjust the setpoint on the Model 604.99957?

A: Adjusting the setpoint is necessary when your application requires switching at a specific pressure within the 0.2 to 3 mbar range. Fine-tuning the setpoint ensures the device responds exactly at your desired differential pressure threshold.

Q: What steps are involved in connecting the Huba Control 604.99957 to an electrical circuit?

A: To connect the device to your electrical circuit, use the flat male connectors (6.3 x 0.8 mm) provided on the switch. Ensure that the voltage and current do not exceed 250 VAC and 1.5 A, respectively. The output is a single-pole double-throw (SPDT) contact for flexible circuit integration.

Q: Where should the Huba Control pressure switch be utilized for maximum benefit?

A: For best results, deploy this switch in environments requiring precise differential pressure monitoring, such as ventilation ducts, filter monitoring, and air conditioning systems, where air or non-aggressive gases are present.

Q: What are the key benefits of using the Model 604.99957 pressure switch?

A: Key benefits include high accuracy, reliable long-term operation, robust construction, simple installation, and compliance with major international standards (CE, RoHS), ensuring safety and peace of mind in a variety of applications.
