DWYER 616KX-100-108-IN DIFFERENTIAL PRESSURE TRANSMITTER

Send Inquiry

Request To Call Back

DWYER 616KX-100-108-IN DIFFERENTIAL PRESSURE TRANSMITTER

Get a Price/Quote

MOQ : 1 Piece

DWYER 616KX-100-108-IN DIFFERENTIAL PRESSURE TRANSMITTER Specification

Display
Analog

Sensor Type
DWYER 616KX-100-108-IN DIFFERENTIAL PRESSURE TRANSMITTER

Usage
POWER PLANT,CEMENT PLANT,STEEL PLANT,FERTILIZER,TEXTILE,Pharmaceutical,POWER PLANT,CEMENT PLANT,STEEL PLANT,FERTILIZER,TEXTILE

Dial Material
Plastic

Size
DWYER 616KX-100-108-IN DIFFERENTIAL PRESSURE TRANSMITTER

Pointer Material
Plastic

Processing Type
Standard

Product Type
DWYER 616KX-100-108-IN DIFFERENTIAL PRESSURE TRANSMITTER

Diameter
DWYER 616KX-100-108-IN DIFFERENTIAL PRESSURE TRANSMITTER

Weight
250 G Grams (g)

Mount Type
Surface

Color
WHITE

Scale Range
DWYER 616KX-100-108-IN DIFFERENTIAL PRESSURE TRANSMITTER

Accuracy
616KX-100±1.0 %FSO

Measure Pressure Of
Gas

DWYER 616KX-100-108-IN DIFFERENTIAL PRESSURE TRANSMITTER Trade Information

Minimum Order Quantity
1 Piece

FOB Port
Delhi

Payment Terms
Paypal, Cash Against Delivery (CAD), Cash on Delivery (COD), Cash Advance (CA), Cash in Advance (CID), Cheque, Days after Acceptance (DA), Delivery Point (DP), Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Western Union, Letter of Credit (L/C)

Sample Policy
If order is confirmed we will reimburse the sample cost

Packaging Details
EXTRA

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India, South India, Central India, West India, North India, East India, Gujarat, Karnataka, Kerala, Lakshadweep, Mizoram, Meghalaya, Manipur, Andhra Pradesh, Bihar, Chandigarh, Daman and Diu, Goa, Jharkhand, Odisha, Punjab, Assam, Delhi, Dadra and Nagar Haveli, Andaman and Nicobar Islands, Arunachal Pradesh, Chhattisgarh, Haryana, Himachal Pradesh, Jammu and Kashmir, Madhya Pradesh, Maharashtra, Nagaland, Rajasthan, Sikkim, Tamil Nadu, Telangana, Tripura, Pondicherry, Uttar Pradesh, Uttarakhand, West Bengal

Certifications
EXTRA

About DWYER 616KX-100-108-IN DIFFERENTIAL PRESSURE TRANSMITTER

DWYER 616KX100108IN DIFFERENTIAL PRESSURE TRANSMITTER

Type 616KX

Manufacturer DWYER OMEGA

Model 616KX100108IN

RANGE 0 to 10 INCH WC

PRESSURE MAX 60 PSI

ACCURACY 616KX10010 FSO

Supply 1035 VDC 1226 VAC

OUTPUT 1 05 010 210 15 VDC

OUTPUT 2 420 mA

COUNTRY OF ORIGIN INDIA

Series 616KX Differential Pressure Transmitters HighPrecision Monitoring for Critical Applications

The 616KX Series Differential Pressure Transmitters Offer Installers and Maintenance Professionals Maximum Flexibility in Pressure Ranges within a compact design As Dwyers smallest differential pressure transmitterit ensures Simplicity With an EdgeMounted PushButton Zero For Easy access in any mounting configuration and features fieldselectable output signalsThe molded housing supports three sizes of both imperial and metric process connections with optional 18 NPT or BSPT Threaded models ensuring easy and flexible process connections

The 616KX Series ensures exceptional stability and repeatabilityminimizing drift and enhancing longterm reliabilityThe robust construction enables operation in demanding conditions while the userfriendly interface allows for easy installation and calibration Available in multiple ranges and outputs these transmitters seamlessly integrate into existing systemsproviding realtime monitoring and control

Product Applications

Duct Pressure

Air Handlers

Variable Air Volume

Filter Monitoring

Specifications

Service Air And NonCombustibleCompatible Gases

Wetted Materials Consult factory

Accuracy 616KX025 025 FSO

616KX050 050 FSO

616KX100 10 FSO

616KX200 20 FSO

Stability 1 year FSO

Temperature Limits 4 F to 159 F 20 C to 70 C

Pressure Limits 36 psig for ranges 0 in wc to 1 in wc 25 Pa to 250 Pa

25 mm wc to 25 mm wc 6 psig for ranges 0 in wc to 40 in wc 500 Pa to 10000 Pa 50 mm wc to 1000 mm wc

Thermal Effect 002 FS F 0036 FS C

Power Requirements 10 Vdc to 36 Vdc 2wire17 Vdc to 36 Vdc or isolated 216 Vac to 33 Vac 3wire

Output Signal 4 mA to 20 mA or option with field selectable 0 V to 10 V0 V to 5 V2 V to 10 V1 V to 5 V

Zero Adjustment Push Button

Loop Resistance 0 Ohms to 1250 Ohms

Current Consumption 21 mA max

Electrical Connections ScrewType Terminal Block

Process Connections BarbedMale Ports for 18 in 316 in 14 in 5 mm 6 mm ID Flexible Tubing

Enclosure Rating NEMA 1 IP20

Mounting Orientation Not Sensitive to Position35 mm DIN Rail side and back Mounting holes for Wall mount with 6 Screws

Weight 18 oz 51 g

Compliance CE RoHS 3Plenum Rated UL 2043UL94 V0

Additional Information

Item Code DWYER 616KX100108IN DIFFERENTIAL PRESSURE TRANSMITTER

WhatsApp No987103410098689589249650264867971664014583688660308368801023

wwwenvirotechindiacoin

wwwenvirotechdelhiin

wwwenvirotechdelhinet

wwwenvirotechindiainfo

wwwenvirotechdelhiinfo

wwwenvirotechindianet

wwwenvirotechdelhicoin
