GEMTECH SERIES G2000-125PA Differential Pressure Gauge Range 125 PA

About GEMTECH SERIES G2000-125PA Differential Pressure Gauge Range 125 PA

GEMTECH SERIES G2000-125PA Differential Pressure Gauge Range 125 PA

Series G2000 GEMTECH Differential Pressure Gauges are Widely Utilized For Measuring Pressure of Fan And Blowing Machine, resistance of Filter, Wind Speed, Furnace Pressure,Differential Pressure Of Pore Plate,The Pressure of drum water level,Liquid Amplifier And Hydraulic Pressure System. Meantime,They Are Used To Control The Automatic Valve And Specific Value Of Air-Producer Gas In Combustion And They Are Used To Test Blood Pressure And Respiratory Pressure In Medical Health Care Equipment.There Are More Than 81 Models To Suit Your Needs Precisely.The Key Components Adopt Import Materi

SPECIFICATION

• Ambient Temperature - -21 140 -6 60

• Rated Pressure -20 inHg30 inHg (-68103KPa)

• Overpressure - Protective rubber stopper will be blown out if rated pressure is up to about 50.8 inHg (172KPa)

• Process Connections - 1/8" female NPT duplicate high and low pressure taps - one pair side and one pair back

• Housing - Die cast aluminum case and bezel, with acrylic cover, Exterior finish is coated gray to withstand 168 Hour Salt Spray Corrosion Test

• Accuracy - 2% of full span at 70 (21 (3% on -0,and 4% on -00)

• Range -20 inHg38 inHg (-68KPa130KPa)(Special Specification also can be ordered.)

FEATURES

• OEM/ODM
• There Is No Need To Fill Liquid To Gauge.
• The Gauge Can Measure Positive Pressure,Negative Pressure And Differential Pressure.
• It Will Be Easy To Install And Measure In Different Ways Because Of Two Groups Of Ports Which Can Measure Positive And Negative Pressure.
• To Eliminate The Friction From The Movement Of Gear Wheel By The Mechanism Of Magnetic Magnet Feed.
• Exact And Stable Fixed Position Of Needle.
• The Gauge Has Great Antiknock Characteristics.
• There Are 81 Types Of Ranges.
• Minimum is 0-60 Pa And Maximum is 0-21-KPa

PRODUCT APPLICATIONS

• Filter Monitoring
• Air Velocity With Pitot Tube
• Blower Vacuum Monitoring
• Fan Pressure Indication
• Duct,Room or Building Pressures
• Clean Room Positive Pressure Indication

MODELS & ORDERING

GEMTECH By Model Number Popularity

• FILTER BY
• Range - Pascals

Model	Description
G2000-30PA	Differential Pressure Gauge,Range 0-30 Pa,minor divisions 1.0, calibrated for vertical scale position
G2000-60PA	Differential Pressure Gauge,Range 0-60 Pa,minor divisions 1.0, calibrated for vertical scale position
G2000-100PA	Differential Pressure Gauge,Range 0-100 Pa,minor divisions 2.0, calibrated for vertical scale position
G2000-125PA	Differential Pressure Gauge,Range 0-125 Pa,minor divisions 5.0 calibrated for vertical scale position
G2000-250PA	Differential Pressure Gauge,Range 0-250 Pa,minor divisions 5.0
G2000-300PA	Differential Pressure Gauge,Range 0-300 Pa,minor divisions 10.0
G2000-500PA	Differential Pressure Gauge,Range 0-500 Pa,minor divisions 10.0
G2000-750PA	Differential Pressure Gauge,Range 0-750 Pa,minor divisions 25.0

Additional Information:

• Item Code: GEMTECH SERIES G2000-125PA Differential Pressure Gauge Range 125 PA
• www.envirotechindustrialproduct.co.in
• www.envirotechindustrialproduct.in
• www.envirotechindustrialproducts.in

High Accuracy and Versatile Measurement

Engineered for superior performance, the GEMTECH G2000-125PA delivers up to 2% full-scale accuracy (with model variations) across its entire range at 70F (21.1C). With various metric and imperial scales, it is adaptable to diverse applications requiring precise differential pressure measurement, including low-range settings as found in cleanrooms and process control.


Rugged Construction for Industrial Applications

This differential pressure gauge employs a durable metal alloy body and alloy pointer with a clear, easy-to-read 4-inch plastic dial. Its rugged design ensures longevity in demanding environments, from power plants to textile mills. Reliable NPT taps and secure back or side mounting further enhance installation flexibility and operational safety.
