GEMTECH* Series 3000 Digital Pressure Gauge Range 0 to 10.00 KPA

Send Inquiry

Request To Call Back

GEMTECH* Series 3000 Digital Pressure Gauge Range 0 to 10.00 KPA

Price 19500 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

GEMTECH* Series 3000 Digital Pressure Gauge Range 0 to 10.00 KPA Specification

Thread
1/8" female NPT duplicate high and low pressure taps - one pair side and one pair back

Outer Size
4" (101.6 MM) Diameter Dial Face.

Display
LCD

Usage
POWER PLANT,CEMENT PLANT,STEEL PLANT,FERTILIZER,TEXTILE

Material
Metal Alloy

Dial Material
Plastic

Pointer Material
Plastic

Size
4" (101.6 MM) Diameter Dial Face.

Processing Type
Standard

Product Type
GEMTECH* Series 3000 Digital Pressure Gauge Range 0 to 10.00 KPA

Diameter
4 inch / 100 MM

Weight
550 Grams (g)

Color
WHITE / BLACK

Mount Type
Back

Scale Range
GEMTECH* Series 3000 Digital Pressure Gauge Range 0 to 10.00 KPA

Accuracy
0.5%

Measure Pressure Of
Gas

Sleep Timer
Yes

Remote Battery Type
AAA

USB Ports
2

Operating System
Android

Viewing Angle
178

Smart TV Features
Built-in WiFi, Screen Mirroring

Refresh Rate
60 Hz

GEMTECH* Series 3000 Digital Pressure Gauge Range 0 to 10.00 KPA Trade Information

Minimum Order Quantity
1 Piece

FOB Port
Delhi

Payment Terms
Paypal, Cash Against Delivery (CAD), Cash on Delivery (COD), Cash Advance (CA), Cash in Advance (CID), Cheque, Days after Acceptance (DA), Delivery Point (DP), Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Western Union, Letter of Credit (L/C)

Sample Policy
If order is confirmed we will reimburse the sample cost

Packaging Details
EXTRA

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India, South India, Central India, West India, North India, East India, Gujarat, Karnataka, Kerala, Lakshadweep, Mizoram, Meghalaya, Manipur, Andhra Pradesh, Bihar, Chandigarh, Daman and Diu, Goa, Jharkhand, Odisha, Punjab, Assam, Delhi, Dadra and Nagar Haveli, Andaman and Nicobar Islands, Arunachal Pradesh, Chhattisgarh, Haryana, Himachal Pradesh, Jammu and Kashmir, Madhya Pradesh, Maharashtra, Nagaland, Rajasthan, Sikkim, Tamil Nadu, Telangana, Tripura, Pondicherry, Uttar Pradesh, Uttarakhand, West Bengal

Certifications
EXTRA CHARGES

About GEMTECH* Series 3000 Digital Pressure Gauge Range 0 to 10.00 KPA

GEMTECH Series 3000 Digital Pressure Gauge Range 0 to 10.00 KPA

GEMTECH* Series 3000 Digital Pressure Gauge Range 0 to 10.00 KPA

GEMTECH _ Series 3000 Digital Pressure Gauge Range 0 to 1.000 KPA Thank You For Choosing Our Digital Differential Pressure Gauge.Please Read This Manual Before Using If You Have Any Doubt About The Use,Please Feel Free To Contact Our Company,We Are Quite Willing To Serve You MATTERS NEEDING ATTENTION Please Do Not Modify The Internal Wiring And Lines Of The Digital Differential Pressure Gauge By Your Self Please Choose a Safe Area To Install The Digital Differential Pressure Gauge To Prevent High Temperature And Avoid Splashing Of Moisture And Water Droplets When The Battery Voltage Is Low,Please Replace The Battery In Time RELEVANT MATTERS BEFORE USE DELIVERY INSPECTION Each Differential Pressure Transmitter is Subject to Strict Quality Control Before Delivery.Product Packaging Adopts Enhanced Anti-Collision Treatment. After Opening The Box,Please Check Whether The Product Caused Damage During The Transportation APPLICATIONS AND FEATURES

Using High-Precision Sensors And Digital Technology,Can Detect Positive Pressure,Negative Pressure Or Differential Pressure
Can Be Widely Used To Measure The Pressure Of Fans And Blowers Filter Resistance Wind Speed Furnace Ventilation Pressure Drop Caused By Orifice Plates,Liquid Level In Foaming Systems And Pressure In Booster Or Hydraulic Systems
Can Be Used On Medical Equipment To Monitor Blood And Respiratory Pressure
Suitable For Embedded Installation,Flat Installation And Other Installation Methods

PRODUCTS SHEET

Various Measuring Ranges
No Moving Parts,Anti-Vibration
Accuracy Up To 1%FS, 3%FS(0-60Pa),2%FS(0-125Pa)
Button Function:Zero Calibration,Unit Switching

STORAGE AND INSTALLATION

The Product Should Be Kept In a Dry And Grime Free Place
Storage Temperature:-10+40
Storage Humidity:0%90%
Vibration:20Hz: 9.8 m/s2 (1G) max;20Hz50Hz:5.88 m/s2 (0. 6G) Max
Avoid Storing in Corrosive Gas And Liquid Environment
It is Best to Store It Properly Packaged On a Shelf Or Table
If it is used in an open package and it exceeds 3 months,The ambient temperature of the storage environment should not be higher than 30 .This is because when the electrolytic capacitor is stored without electricity,its characteristics are easily deteriorated when the ambient temperature is too high.Do not leave it for more than a year without electricity
Ambient Temperature:-10+50 (14104)
Ambient Relative Humidity:<90%,no frost
Installation Height:<1000m

On a circle with a diameter of 105mm,drill 3 holes with an average angle of 120 degrees.The hole diameter is between 3-3.2 (as shown in the picture above). Mounted on The Surface With Accessory Screws M3X8.Choose one Pair of Pressure ports to connect to the Air Tube,Pay attention to the Difference Between High and Low Pressure Ports,And Make Sure to Seal the other pair of pressure ports with On the plate that needs to be embedded,punch a hole, the diameter of the hole is between 114 and 3-114.8mm.Embed the product and install the accessory feet on the back.Then fix it on the plate with M3.5X50 self-tapping screws.Choose one of the pair of pressure ports to connect to the Airway Note the Difference Between High/Low Pressure Ports And Make Sure To Seal The Other PRODUCT PARAMETERS

Medium:Air And Non-Flammable,Non-Corrosive Gas
Medium Temperature: 0-60C
Shell:ABS Engineering Plastic
Working Environment:-20Ci+85C
Differential Pressure Range:a variety of Ranges.Overload 3xFS,Breaking pressure 10FS
Long-Term Stability:0.1% FS/Year
Temperature Drift Coefficient: <0.03% FS/C
Power Supply:4 AA Batteries / 24 VDC

Item Code: GEMTECH* Series 3000 Digital Pressure Gauge Range 0 to 10.00 KPA
WhatsApp No.9871034100,9868958924,9650264867,9716640145,8368866030,8368801023
www.envirotechindustrialproduct.net
www.envirotechindustrialproductsindia.in
www.envirotechindustrialproductsdelhi.com
www.envirotechindustrialproduct.info
www.envirotechindustrialproducts.info
www.envirotechdelhi.com
www.envirotechindia.co.in

GEMTECH Series 3000 Digital Pressure Gauge Range 0 to 10.00 KPA

Reliable Pressure Measurements for Industrial Use

The GEMTECH* Series 3000 is engineered for industries where accurate pressure monitoring is critical. Its sturdy design and clear digital readout enable smooth operations in settings like power, steel, or fertilizer plants. The 4-inch dial face offers clear visibility, while the lightweight and robust construction facilitates effortless installation.

User-Friendly Features and Installation Flexibility

This digital pressure gauge comes equipped with duplicate high and low pressure taps on both the side and back, allowing for flexible mounting and connection. Its back-mounted configuration and standard thread ensure broad compatibility with industrial systems, simplifying the installation process.

FAQ's of GEMTECH* Series 3000 Digital Pressure Gauge Range 0 to 10.00 KPA:

**Q: How is the GEMTECH* Series 3000 Digital Pressure Gauge installed?**

A: The gauge features a back mount and standard 1/8" female NPT threads, with duplicate high and low pressure taps on the sides and back. This design allows easy installation into existing industrial systems, ensuring a secure and adaptable fit.

Q: What is the typical usage of this digital pressure gauge?

A: This gauge is ideally suited for monitoring gas pressure in power plants, cement plants, steel plants, fertilizer industries, and textile factories, where consistent and precise readings are essential for safe and efficient operations.

**Q: When should I calibrate or check the GEMTECH* Series 3000 for accuracy?**

A: For optimal performance, it is recommended to calibrate or verify the gauge at intervals specified by your plant's maintenance protocol, or whenever there is a suspicion of deviation from its rated 0.5% accuracy.

**Q: Where can the GEMTECH* Series 3000 be used?**

A: The device is suitable for both indoor and protected outdoor environments across various industries. Its robust construction supports installation in locations with regular industrial conditions, provided the device is shielded from direct weather exposure.

Q: What are the benefits of using a digital pressure gauge with a LCD display?

A: The LCD display offers clear, easy-to-read pressure measurements, reducing reading errors and facilitating quick monitoring, which enhances workplace safety and operational efficiency.

Q: How does the gauge ensure durability in demanding environments?

A: With a metal alloy body, plastic dial, and pointer, the GEMTECH* Series 3000 withstands industrial conditions. Its design helps prevent corrosion and damage, ensuring long service life and dependable operation.
