Setra 3100B0200S01B Control Pressure Transmitter 0-200 Bar

3100 Series Information

• 0-100 psi to 0-30,000 psi ranges (0-7 bar to 0-2,200 bar)
• Broad Choice of Outputs
• High Proof Pressures
• RoHS Compliant

For OEMs that need consistent high levels of performance, reliability and stability the 3100 and 3200 Series sputtered thin film units offer unbeatable price performance ratio in a small package size. They feature allstainless steel wetted parts, a broad selection of electrical and pressure connections, and wide choice of electrical outputs to allow stock configurations suitable for most applications without modification. At the heart of both these series is a sputter element that also provides exceptional temperature specifications. Plus, our manufacturing process for the 3100 and 3200 Series include the latest automated equipment, producing the most consistent and best price to performance sensor on the market today.
Additionally, 3200 Series Transmitters feature thicker diaphragms and a pressure restrictor to withstand the rigors of cavitations or extreme pressure spikes, delivering years of reliable and stable performance in pulsating applications.
The compact construction of both these series makes them ideal for installation where space is at a premium and they are fully RoHS compliant.

Specifications

• Item Number:  3100B0200S01B
• Brand: Gems Sensors & Controls
• Item Category: Transducers
• Subcategory: Pressure Transducers
• Series: 3100
• Pressure Range (Gauge): 0~200 bar
• Max Pressure (Gauge): 200 bar
• Type: OEM
• Input: 8~30 VDC
• Output: 4~20 mA
• Electrical Connection: DIN 43650 Form C
• Pressure Connection: G 1/4-18 NPT Male
• Enclosure Rating: IP 67
• Temperature Range: -40 to 257 Degrees F
• Approvals: CURUS
• RoHS: Yes
